PB-1 Polybutylene Pipe for Underfloor Heating

PB-1 Polybutylene Pipe for Underfloor Heating
PB-1 Polybutylene Pipe for Underfloor Heating
PB-1 Polybutylene Pipe for Underfloor Heating is a kind of PB-1 material that of Light weight, easy transportation and installation. It is used for underfloor heating in both household and office.

PB-1 Polybutylene Pipe for Underfloor Heating is a kind of PB-1 material that of Light weight, easy transportation and installation. It is used for underfloor heating in both household and office.

PRODUCT DESCRIPTION

Product Description
PB-1 Polybutylene Pipe for Uunderfloor heating is a kind of PB-1 material that of Light weight, easy transportation and installation. It is used for underfloor heating in both household and office.

Features
-  Light weight, easy transportation and installation
-  Chemical stability and durability: service life of up to 100 years
-  UV-ray and corrosion resistance, assuring high quality of purified water
-  Low and high temperature resistance: performs well under the temperature from -20ºC   to 110ºC
-  High flow capacity with smooth surface
-  No leakage assurance with butt welding
-  Energy saving: 30% less than that of steel pipe
-  Easy maintenance and renovation: does not bond with concrete
Specification

Program

Indicator

Longitudinal retraction rate, %,110ºC

≤2%

Hydrostatic strength

20ºC,hoop stress15.5Mpa,1h, no broken,
no leakage

95ºC,hoop stress6.5Mpa,22h, no broken,
no leakage

95ºC,hoop stress6.2Mpa, 165h, no broken,
 no leakage

95ºC,hoop stress6.0Mpa,1000h, no broken,
no leakage

Internal pressure resistance test

95ºC,pressure1.19Mpa,1000h,no broken,
 no leakage

Melt mass-flow rate
(190ºC,5kg),g/10min

The difference to raw material test should no
exceed 0.3g/min


Product Name:
PB-1 Polybutylene Pipe for Underfloor Heating
Brand:
Santi Chemical
Size:
16mm-40mm
Wall Thickness:
2.0mm-5.5mm
Nominal Pressure:
2.0Mpa
Material:
Polybutene Netherlands Basell
Color:
Ivory,grey or customized
Length:
4m,6m of straight,100m/coil or as requested
Packing:
In coils or 6-12m/piece by plastic bag
Connection:
butt fusion, electro-fusion
Standard:
GB/T19473.2-2004
Service Life:
Minium 50 years life under normal condition
Application:
Floor heating system, water supply,irrigation,etc
